WB11 Series

WB11 Series

Product Name Height
mm		 Width
mm		 Thickness
mm		 Plumbing Axes Center to center
mm		 Wall to Pipe center
mm		 Wall Distance
mm		 Tube Quantity
H W D C - -
WB11-4/1600 1600 304 46 1555 46 66 4
WB11-6/1600 1600 456 46 1555 46 66 6
WB11-4/1800 1800 304 46 1755 46 66 4
WB11-6/1800 1800 456 46 1755 46 66 6
WB11-6/600 600 456 46 555 46 66 6
WB11-8/600 600 608 46 555 46 66 8
WB11-11/600 600 836 46 555 46 66 11
WB11-14/600 600 1064 46 555 46 66 14
WB11-17/600 600 1292 46 555 46 66 17
